SS36 DO-214AC SMA 3A Surface Mount Schottky Rectifier Diodes 60V

Name: SS36 DO214AC SMA 3A Surface Mount Schottky Rectifier Diodes 60V
Brand: SFST
Price: 1 USD

Wholesale SS36 DO-214AC SMA 3A Surface Mount Schottky Rectifier Diodes 60V from china suppliers

Brand Name : SFST

Model Number : SS36

Certification : CE/ RoHS

Place of Origin : Original

MOQ : 10pcs

Price : To be negotiated

Payment Terms : T/T, Western Union ,paypal

Supply Ability : 10,000PCS

Delivery Time : in stock 2-3days

Packaging Details : 2000pcs/ Reel

PN : SS36

Package : DO-214AC ( SMA )

Operating Temperature : -55°C to +150°C

Type : 3 Amp Schottky Rectifier

Voltage : 60V / 20 to 100 Volts

igh Temp Soldering : 260 °C

Current : 3A

Contact Now

SS36 # DO - 214AC ( SMA ) 3 Amp Surface Mount Schottky Rectifier Diodes 20 to 100 Volts

Features
●Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates Compliant. See ordering information)
●Halogen free available upon request by adding suffix "-HF"
●High Current Capability With Low Forward Voltage
●High Temp Soldering: 260 °C for 10 Seconds At Terminals
●Epoxy meets UL 94 V-0 flammability rating Moisture Sensitivity Level 1

●Maximum Recurrent Peak Reverse Voltage :60V

●Maximum RMS Voltage : 42V

●Maximum DC Blocking Voltage: 60V

Maximum Ratings
●Operating Temperature: -55°C to +150°C
Storage Temperature: - 55°C to +1 50°C
●Maximum Thermal Resistance :20°CN Junction To Case
●Maximum Thermal Resistance :1 0°C/W Junction To L ead
Maximum Thermal Resistance :55°CN Junction To Ambiemt

SS36 DO-214AC SMA 3A Surface Mount Schottky Rectifier Diodes 60V

Deli electronics tehcnology Co.,Ltd
Email:sales3@deli-ic.com
Skype:hkdeli881
Contact: VIVI-CHEN
